High Speed Roller Shutter Door Roll Forming Machine Automatic Metal Slat Making Equipment for Industrial Security Gate
Introducing our high-performance Roller Shutter Door Roll Forming Machine, the ideal production solution for professional door manufacturers and construction projects. This fully automatic machine is engineered to streamline the manufacturing of high-grade roller shutter door profiles, helping you boost productivity and gain a strong competitive advantage in the industry.
Built with an 80*80 square tube heavy-duty frame and 15 precision-forming passes, the machine ensures stable and consistent profile forming quality. Featuring 16mm thick wall plates and Φ50mm solid 45# steel main shafts, it provides outstanding structural rigidity and long-lasting durability, supporting continuous heavy-duty operation with no loss of performance.
Driven by a 4KW main motor and a 4KW air-cooled hydraulic pump station, the machine uses a dependable gear transmission system to deliver steady and smooth running. Its adjustable production speed ranges from 15-16m/min for optimized output, while the high-efficiency power design lowers energy consumption and reduces overall production costs.
Equipped with a high-end Delta PLC control system and variable frequency technology, the machine enables extremely accurate control over the full production flow. The post-forming double-blade shearing structure ensures clean, burr-free cuts with low maintenance requirements, delivering a cutting length tolerance of ≤1mm to satisfy strict quality specifications.
The machine is fitted with 35mm galvanized pull rods and a Type 4 cycloidal reducer for reliable and stable performance. Supporting both Chinese and Russian operating languages, it is well-suited for international users. Its rugged structure guarantees a long service life and consistent, high-quality performance over years of use.
Frequently Asked Questions
Can a single machine produce multiple types of profiles?
Standard models are typically designed to produce one specific profile type per machine. However, customizable models—such as those with interchangeable rollers, double-layer machines, or triple-layer machines—can be configured to enable a single machine to serve multiple purposes.
Does the machine require disassembly for transport?
The core structure remains intact; only the auxiliary components are removed to ensure that precision is maintained.
There are no professional maintenance personnel available locally; what should we do in the long run?
We provide lifetime remote video guidance; most issues do not require on-site repair.
Is the length of the discharge rack adjustable?
Yes, our standard telescopic discharge rack can be adjusted to accommodate sheet materials of varying lengths.
Are customers able to visit the factory to test the machine and observe its performance firsthand?
We welcome customers—or a designated third party—to visit our factory to inspect the machine and conduct trial production runs using their own materials.
